Building custom wheels with Forgestar is easy. Here is what you can expect:
Description
- Custom bolt patterns
- Rotary formed flow formed barrel
- Big brake kit clearance
- Wide range of wheel widths
- Superior offset range
- Drilled to cone seat specs
*Conical/tapered lug nuts will be required.
CF5V FITMENT CHART
Forgestar CF5V wheels are available in a variety of sizes and offsets to accommodate different vehicle platforms and performance needs:
- Diameters: 19" and 20"
- Widths: 8.5" to 12"
- Offsets: From -25mm to +83mm
These options allow for precise fitment, whether you're aiming for a flush stance or a more aggressive setup. The wheels are also designed to clear most big brake kits, making them suitable for high-performance applications .
| Semi Concave | Semi Concave Offset Range | Deep Concave | Deep Concave Offset Range | Super Deep Concave | Super Deep Concave Offset Range |
|---|---|---|---|---|---|
| 19×8.5 | +10 to +54 | 19×9.5 | -2 to +48 | 19×9.5 | -25 to +25 |
| 19×9.0 | +12 to +60 | 19×10 | +4 to +54 | 19×10 | -19 to +30 |
| 20×9.0 | +12 to +59 | 19×11 | +17 to +67 | 19×11 | -6 to +40 |
| 20×11 | +24 to +71 | 19×12 | +6 to +53 | 19x12 | +6 to +53 |
| 20x10.5 | +17 to +63 | ||||
| 20x11 | +24 to +71 | ||||
| 20x12 | +36 to +83 | ||||
| 20x13 | +49 to +96 |
CF5V Deep Concave Custom Finishes
Forgestar provides a variety of finish options to complement your vehicle's look, including the finishes below. Additionally, custom finishes are available upon request, allowing for further personalization.
CF5V Custom
